TSBL
$765.00
LED Illuminated Track Stand with Coarse Focus Rack
- Stable, shake-resistant track stand for microscopes
- Coarse focus rack
- 76mm scope holder which suits most microscopes
- 385mm focus distance
- Includes a 95mm black/white contrast plate and a clear glass plate
- LED bottom light base (dimmable)
Description
Track Stand with Focus Rack and LED Backlighting
- Long continuous track for easy moving up and down of microscope
- Coarse focus rack
- 76mm scope holder suitable for most microscopes
- 385mm focus distance
- Includes a 95mm black/white contrast plate and a clear glass plate
- LED bottom light base for backlighting (dimmable)
- Perfect for medical devices
Specifications
| Track Stand | ||
| Stand Type | Track Stand | |
| Holder Adapter Type | 76mm diameter scope holder | |
| Track Length | 520mm | |
| Base Type | Illumination Base | |
| Stand Throat Depth | 120mm | |
| Base Dimensions | 320x316x21mm | |
| Focus Mode | Manual | |
| Focus Distance | 385mm | |
| Coarse Focus Distance per Rotation | 23mm | |
| Focus Knob Tightness | Adjustable tightness | |
| Illumination Type | LED Transmitted Light | |
| Input Voltage | AC90-240V 50/60Hz | |
| Output Voltage | DC6/12/24V | |
| Power Cord Connector Type | USA 3 pins | |
| Power Cable Length | 1.8m | |
| Material | Metal | |
| Color | White | |
| Net Weight | 4.65kg (10.25lbs) | |
| Dimensions | 320x316x550mm (12.598×12.441×21.654 in.) | |
| Microscope Plate | ||
| Plate Type | Black White Plate | |
| Plate Size | Diameter 95x5mm | |
| Material | Plastic (ABS) | |
| Plate Type | Clear Glass Plate | |
| Plate Size | Diameter 95x5mm | |
| Material | Clear Float Glass | |
