BM1000CTL
$2,250.00
40X-1,000X LED Trinocular Biological Microscope
- 40-1,000X Total Magnification
- 10X High Eyepoint Eyepiece
- 4X 10X 40X 100X Infinity Plan Achromatic Objective
- LED Coaxial Transmitted Light
- Trinocular Port for Camera Connection
- Input Voltage: AC 100-240V 50/60Hz
- Select Camera and LCD options to add to the microscope.
Description
Options
Select Camera and LCD options to add to the microscope.
40X-1,000X LED Trinocular Biological Microscope
This modern biological microscope is designed for research in veterinary medicine, bacteriology, immunology, pharmacy, and other scientific fields. It is equipped with a trinocular port that allows you to connect any C-Mount microscope camera for simultaneous viewing and capturing through the camera. The microscope has an infinity-corrected optical system with precise micro and macro focus adjustment and a wide field of view, up to 22 mm.
The high-quality plan achromatic lenses offer detailed images, while the large table is practical and user-friendly. It also has hidden gears and moves about the tripod only in the Y-axis direction, saving space on the microscope’s sides. The holder allows you to mount two specimens and compare them quickly.
Featuring LED lighting (high brightness and long service life), the cold white light does not heat the microscope and the specimen, which is especially useful for very long, uninterrupted observations.
Key Features
- 40-1,000X Total Magnification
- 10X High Eyepoint Eyepiece
- 4X 10X 40X 100X Infinity Plan Achromatic Objective
- Standard Coupler: 0.5X
- 30° Eye Tube Angle
- Eyepiece Field of View: Dia. 22mm
- XY Stage Travel Distance: 78x54mm
- LED Coaxial Transmitted Light
- Trinocular Port for Mounting Camera
- Input Voltage: AC 100-240V 50/60Hz
Applications
- Clinical Laboratory
- Biological Education
- Life Science Research
- Veterinary Medicine
- Bacteriology
- Immunology
- Pharmacy
BM05100303-1
Specifications
| Optical System | Infinite |
| Total Magnification | 40-1000x |
| Standard Eyepiece | 10x High Eyepoint Eyepiece |
| Standard Objective | 40x 10x 40x 100x Plan Achromatic Objective |
| Field of View | Dia. 0.22-5.5mm |
| Stand Height | 310mm |
| Base Type | Illumination Base |
| Base Dimensions | 220x290x70mm |
| Focus Mode | Manual |
| Illumination Type | LED Coaxial Transmitted Light |
| Input Voltage | AC 100-240V 50/60Hz |
| Power Cord Connector Type | USA 3 Pins |
| Cable Length | 1.8 meters |
| Weight | 8.90kg (19.62 lbs) |
| Overall Dimensions | 220x290x400mm (8.661×11.417×15.748 in.) |
